Expert IC layout design, on demand.
TechChip Engineering BV is an independent IC layout design consultancy. We help semiconductor teams craft analog, mixed-signal and RF layouts that hit performance, area and yield targets — from first floorplan to tape-out.
- Analog, mixed-signal & RF layout
- Advanced & mature node experience
- DRC / LVS clean tape-outs
- EU-based, on-site available
IC layout consulting, end-to-end
A focused service offering — built around a single discipline, executed by senior layout engineers.
Full-Custom IC Layout
Hand-crafted analog, mixed-signal and RF layout optimised for performance, area and yield.
Analog & Mixed-Signal Blocks
Layout of bandgaps, ADCs, DACs, PLLs, LDOs, SerDes and other critical analog IP.
Floorplanning & Top-Level Integration
Hierarchical floorplanning, power grid planning and top-level assembly for complex SoCs.
DRC, LVS & Sign-Off
Physical verification, parasitic extraction and tape-out sign-off across leading PDKs.
ESD, Latch-Up & Reliability
ESD protection strategy, latch-up prevention and electromigration / IR-drop aware layout.
Layout Consultancy & Mentoring
On-site or remote senior support to accelerate your team and de-risk critical projects.
Have an idea worth engineering?
Tell us about your product. We'll respond within one business day with the right team and a clear next step.
